Product description
These metal drill bits made of HSS is ideal for drilling into hard materials such as steel. The 118° tip angle makes pilot drilling easier and ensures fast drilling progress; the ground cutting edge ensures excellent drilling performance during continuous use. The bit is precision ground for high true running accuracy; the increasing core provides high stability and minimises the risk of breakage. The decreasing diameter reduces heat build-up and thus helps to preserve the drill bit and materials. The large chip guide groove ensures effective chip removal. The metal drill bit is available in different sizes and has a ¼" hexagon shank for quick tool changes in bit holders. It is compliant with DIN 338.
Suitable for material
- Very suitable Steel, Cast iron, Iron, Non-ferrous metal, Aluminium, Plastic
Properties
- metal drill bit made of HSS for drilling into hard materials such as steel
- 118° tip angle makes pilot drilling easier and ensures fast drilling progress
- ground cutting edge – for high durability and excellent drilling performance during continuous use
- precision ground for high true running accuracy – ideal for stationary drilling
- increasing core for high stability and minimised risk of breakage
- decreasing diameter for reduced heat build-up helps to preserve the drill bit and materials
- large chip guide groove for effective chip removal
- available in different sizes
- ¼" hexagon shank for quick tool changes in bit holders
- compliance with DIN 338 ensures that it's a safe product choice
Technical data
- Material High-Speed Steel (Hss)
- Manufacture process Precision ground
- Drill tip angle 135°
- Shank version Hexagon shank A/F 6.35 mm (¼")
- Direction of rotation Clockwise rotation
- According to standard DIN 338
- Additional product specification spiral section with decreasing diameter and increasing core
